Hybrid stepper motor PKP series 4-wire flat type 51-61 mm Oriental Motor

Parts	Frame size	Inductance	Maximum Holding Torque	Rated Current	Rotor Inertia	Step angle	Weight	Winding Resistance	Voltage
PKP Series stepper motor, 2-Phase, 42mm frame, 4 leads, single shaft, harmonic gear Art: PKP242D23A2-H50 Copied	51 mm	0.53 mH/Phase	1.8 Nm	2.3 A/Phase	17x10⁻⁷	0.036 °	0.32 kg	0.61 Ω/Phase	1.4 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 4 leads, single shaft, harmonic gear Art: PKP242D23A2-H100 Copied	51 mm	0.53 mH/Phase	2.4 Nm	2.3 A/Phase	17x10⁻⁷	0.018 °	0.32 kg	0.61 Ω/Phase	1.4 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 4 leads, single shaft, harmonic gear Art: PKP262FD15AW-H50S Copied	61 mm	0.8 mH/Phase	3.5 Nm	1.5 A/Phase	83x10⁻⁷	0.036 °	0.54 kg	1.1 Ω/Phase	1.65 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 4 leads, single shaft, harmonic gear Art: PKP262FD15AW-H100S Copied	61 mm	0.8 mH/Phase	5 Nm	1.5 A/Phase	83x10⁻⁷	0.018 °	0.54 kg	1.1 Ω/Phase	1.65 V DC

Select a variant in the list

Oriental Motor Bipolar 4-Wire Flat Type With Harmonic Gear PKP Series Hybrid Stepper Motor
