General Data |
|
|---|---|
| Nominal speed | 3000 rpm |
| Nominal torque | 0,4 Nm |
| Input voltage dc | 24/48 Vdc |
| Digital inputs | 2 pnp (24Vdc, 500kHz) , 3 pnp (24Vdc, 7kHz) |
| Outputs | 1 NO 2A (42 Vdc) |
| Output power | 125 W |
| Rated current | 8A@24V/4.2A@48V A |
| Nominal overload | 200% x 60 sec |
| Motor control algorythm | Sinusoidal brushless with 12Bit single-turn / 20Bit multi-turn absolute encoder |
| Nominal output frequency carrier | 4/8/12 kHz |
| Electronic brake output | 24Vdc, max 0.5A |
| Ambient temperature | -10 ... +40°C |
Safety Features |
|
| IP class | IP65 |
| CE approved | Yes |
| Over voltage protection | Yes |
| Under voltage protection | Yes |
| Overheat protection | Yes |
| Memory error protection | Yes |
| Polarity reverse protection | Yes |
| Overcurrent protection | Yes |
| Communication error protection | Yes |
| Overload protection | Yes |
Communication |
|
|---|---|
| Communication | USB |
| Ethercat | Yes |
| CanOpen | Yes |
| ProfiNET | Yes |
| Ethernet IP | Yes |
| Modbus RTU | Yes |
| PowerLink | Yes |
Automated machinery in the process and packaging industries is constantly developing. Find out how we can help to automate process and packaging machinery at OEM.
After 2 years, OEM are thrilled to announce that we are returning to PPMA this September! Save the dates and visit us on stand A70!
The Mini Motor IP69K, stainless steel product range was designed to conform to guidelines mandated by the E.H.E.D.G. Let’s look into how Mini Motor are providing stainless-steel solutions.
In automation, components must be able to stand up to harsh environments and be long-lasting. See what IP69K product we recommend and where they can be used.
Chemical processing and production are part of a huge billion-pound industry. The importance of chemistry means there is no room for inaccuracies.
OEM Automatic's Motors department have a new updated overview brochure, Read Here! Also see updates from Motors Supplier DOGA!
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Parts | Nominal torque | Input voltage dc | Output power | Rated current | Nominal overload | Price | ||
|---|---|---|---|---|---|---|---|---|
|
24/48 Vdc, 3000rpm, 0.4nm, 125W
Art:
DBS-S3 55/50
Copied
|
0,4 Nm | 24/48 Vdc | 125 W | 8A@24V/4.2A@48V A | 200% x 60 sec |
| ||
|
48 Vdc, 3000rpm, 0.75nm, 250W
Art:
DBS-S3 55/100
Copied
|
0,75 Nm | 48 Vdc | 235 W | 6.3 A | 200% x 60 sec |
| ||
|
48V dc, 3000rpm, 1.1nm, 345 W
Art:
DBS-S3 80/50
Copied
|
1,1 Nm | 48 Vdc | 345 W | 9.9 A | 150% x 60 sec |
| ||
|
48V dc, 3000rpm, 2.1nm, 660 W
Art:
DBS-S3 80/100
Copied
|
2,1 Nm | 48 Vdc | 660 W | 15.7 A | 150% x 60 sec |
|
Select a variant in the list
