FLEXA
ROHRflex PA6-S is spesifically made for cold environments. Internally and externally corrugated, halogen-free.
Â
Supplied in full packages, also available in grey color.
| Approvals | CE, CSA US, DNV, Lloyd´s, RU, UL, VDE |
|---|---|
| Bending radius ±10% dynamic | 35 |
| Bending radius -10% static | 13 |
| Colour | Black |
| Fire rating | UL94-V2 |
| Hose dimension AD | 10 |
| Inner dimensions | 6,5 mm |
| Material | Polyamide |
| Outer dimensions | 10 mm |
|---|---|
| Pack size | 50 m |
| Temperature operational max | 120 °C |
| Temperature operational min | -40 °C |
| Type | ROHRFLEX -PA6-S |
| Weight / m | 0,02 |
ROHRflex PA6-S is spesifically made for cold environments. Internally and externally corrugated, halogen-free.
Â
Supplied in full packages, also available in grey color.
Optimise your production line with encoders, inclinometers, displays and slip rings
Engineers and technicians are seeking solutions that streamline assembly whilst maintaining high levels of protection and flexibility. KDS-SR90 angled screw frames and inlays bring a new level of efficiency to cable routing with a unique 90° entry design.
The smallest logic controller by Crouzet is now 20% off for a limited time only! A powerhouse packed into just 17.5mm! Efficiency, adaptability, and seamless integration with free software.
Do you require signalling devices and beacons in your production process? Download our latest whitepaper!
Here, our customer requires control boxes for electricity metering systems. We leveraged our expertise to deliver easy-to-install, ready-to-use assemblies. We look forward to creating more of these bespoke control boxes for our customer.
This blog talks all things DC circuit protection including the key components: electronic circuit breakers, fuses and current monitoring devices. As well as how to choose the right protection.
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Parts | Bending radius ±10% dynamic | Bending radius -10% static | Hose dimension AD | Inner dimensions | Outer dimensions | Pack size | Weight / m | Price | ||
|---|---|---|---|---|---|---|---|---|---|---|
Plastic tube-PA6-S AD 10,0 Black
Art:
0233.209.006
Copied
|
35
|
13
|
10
|
6,5 mm
|
10 mm
|
50 m
|
0,02
|
| ||
|
Plastic tube-PA6-S AD 13,0 Black
Art:
0233.209.010
Copied
|
45
|
20
|
13
|
10 mm
|
13 mm
|
50 m
|
0,03
|
| ||
|
Plastic tube-PA6-S AD 15,8 Black
Art:
0233.209.012
Copied
|
55
|
35
|
15,8
|
12 mm
|
15,8 mm
|
50 m
|
0,038
|
| ||
|
Plastic tube-PA6-S AD 18,5 Black
Art:
0233.209.014
Copied
|
65
|
40
|
18,5
|
14,3 mm
|
18,5 mm
|
50 m
|
0,052
|
| ||
|
Plastic tube-PA6-S AD 21,2 Black
Art:
0233.209.016
Copied
|
75
|
45
|
21,2
|
16,5 mm
|
21,2 mm
|
50 m
|
0,063
|
| ||
|
Plastic tube-PA6-S AD 28,5 Black
Art:
0233.209.023
Copied
|
100
|
55
|
28,5
|
23 mm
|
28,5 mm
|
50 m
|
0,103
|
| ||
|
Plastic tube-PA6-S AD 34,5 Black
Art:
0233.209.029
Copied
|
120
|
65
|
34,5
|
29 mm
|
34,5 mm
|
25 m
|
0,142
|
| ||
|
Plastic tube-PA6-S AD 42,5 Black
Art:
0233.209.036
Copied
|
150
|
90
|
42,5
|
36 mm
|
42,5 mm
|
25 m
|
0,159
|
| ||
|
Plastic tube-PA6-S AD 54,5 Black
Art:
0233.209.048
Copied
|
190
|
100
|
54,5
|
48 mm
|
54,5 mm
|
25 m
|
0,22
|
|
Select a variant in the list
