Selected variant
Technical data
| Coding | A |
|---|---|
| Connection | M12 |
| IP class | IP67 |
| Manufacturer part no. | 1200110013 |
| Mounting | Front flange |
| Number of poles | 4 |
| Panel mounting | M14 |
| Rated current | 4 A |
|---|---|
| Rated wire cross section | 0.34 mm² |
| Wire length | 300 mm |
| Voltage ac max | 250 V |
| Voltage dc max | 250 V |
