Servo Motors
They are available in a various configurations, from fully integrated stand-alone products which include a drive and motion controller, to BLDC motor-only options with a single encoder for commutational feedback, these require external components to drive and control them.
Integrated options offer simplified set up and reduce the cabling and overall component count required to implement into a control system.
The motors have variants that allow integration into most frequently encountered industrial bus networks - CANopen, EtherCAT and RS485 Modbus.
Motors are available both with or without a brake, and many feature STO functionality. Ingress protection to IP65 is generally standard.
Dedicated companion servo drives offer tuneless set up over USB using free PC software, and make system set up as straightforward as possible.
MBDV DC Servo Motor
MBDV series low voltage DC servo motors, frame sizes from 40-130mm, power range from 100-1500W, IP65 rated
- Wide range of frame sizes 40-130mm
- Power outputs from 100-1500W (0.32-4.7Nm)
- Tuneless set up with MBDV controllers and Luna PC software
- Supports CANopen and RS485 comms with wireless AGV option
- IP65 protection with brake and STO options
MDX+ Integrated Servo Motor
MDX Plus - Fully integrated feature-rich servo motor system offering pulse, RS485, CANopen and EtherCAT communication modes
- Ultra compact servo motor with integrated motion controller
- Supports CANopen, EtherCAT and RS485 communication
- Torque up to 1.8Nm at 3000rpm
- Easy set up with dedicated software
- Options for brake, STO and IP65 protection
MSD Driving Wheel
Modular fully integrated drive wheel range specifically developed for mobile robots
- 150-200mm drive wheels with brake option
- 24-60Vdc supply with built in 16-bit encoder - 2500ppr
- Delivers up to 50Nm at wheel at 2.8m/s
- STO (SIL3) function with dynamic and emergency braking
- Compact in size and quiet running with elastic suspension
Jacking, lifting and rotating motors for AGV's
BLDC motor with encoder for jacking and rotating in AGV applications, ideally suited for use with MOONS' MDS drive wheel range and MBDV servo drives
- BLDC motor with 16 bit encoder, options with and without brake
- 60mm (400W) and 80mm (750W) frame size options
- 3000rpm with 1.7Nm and 2.4Nm nominal torque
- Ideally suit for lifting and rotating in AGV applications
- Ideally suited for use with MDS drive wheels and MBDV servo drives
Mini MBDV DC Servo Motors
MBDV miniature series low voltage DC servo motors in 20mm frame size with 30W output, differential and SPI encoder options. CANopen, EtherCAT, RS485 Modbus comms
- Super compact 20mm frame size
- Coreless motor design for maximum power density
- 30W output (3000rpm @ 0.01Nm)
- Tuneless set up with MBDV controllers and Luna PC software
- Supports CANopen, EtherCAT and RS485 communication
MBDV Servo Drive
DC servo drive configured for ease of implemenation in AGV applications. Multi axis with STO functionality
- Single and dual axis AGV specific drive
- 20A/60A peak and 40A/120A peak versions
- CANopen and Modbus RTU communication options
- Easy set up with dedicated Luna softare
- Regenerative and dynamic braking with STO function (SIL2 compliant)
