| Approvals | CE |
|---|---|
| Detection height | 50 mm |
| Distance max | 500 mm |
| Distance min | 100 mm |
| Electrical connection | Casting cable 3 m |
| Function | light on |
| IP class | IP67 |
| Lens material | Plastic |
| Light type | IR LED |
| Light/dark switching | No |
| Material of body | Aluminium |
| Number of bulbs | 5 |
|---|---|
| Output | PNP |
| Output current max | 0.1 A |
| Photocell technology | Curtain photocell |
| Power consumption max | 0.08 A |
| Reaction time | 8 ms |
| Temperature operational max | 55 °C |
| Temperature operational min | -25 °C |
| Voltage dc max | 24 V |
| Voltage dc min | 12 V |
We are pleased to announce that OEM Automatic Ltd has acquired Motion29 Ltd. Bringing together the expertise, products, and services of both organisations under both the OEM and Motion29 brands, strengthening our overall offering.
Discover how fault masking is compromising the safety of your workplace and find out how OEM Automatic can help you to prevent it completely. Creating a safe and secure work environment.
Learn more about Inxpect radar systems. The worlds first SIL 2/PL d certified, radar-based safety system for use around hazardous machinery.
Whether you're working with opaque materials or transparent items like glass or plastic, these sensors deliver reliable performance across a wide range of applications.
OEM Automatics Safety Experts guide you through the process of setting up your light curtains & barriers, to protect your people and equipment.
Ultra fast-acting fuse links engineered specifically to shield delicate semiconductor devices.
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Parts | Detection height | Distance max | Distance min | Number of bulbs | Output | Price | ||
|---|---|---|---|---|---|---|---|---|
WIDE SENSOR 100-500MM H=50MM
Art:
SSCT805-PNP
Copied
|
50 mm
|
500 mm
|
100 mm
|
5
|
PNP
|
|
||
|
Light curtain H=100mm 150-800mm
Art:
SSCT810-PNP
Copied
|
100 mm
|
800 mm
|
150 mm
|
10
|
PNP
|
|
||
|
Light curtain H=100mm 0,5-2,5m
Art:
SSCT830-PNP
Copied
|
100 mm
|
2500 mm
|
500 mm
|
10
|
PNP
|
|
||
|
Light curtain H=100mm 150-800mm
Art:
SSCT810-NPN
Copied
|
100 mm
|
800 mm
|
150 mm
|
10
|
NPN
|
|
||
|
WIDE SENSOR 150-800MM H=150MM
Art:
SSCT850-PNP
Copied
|
150 mm
|
800 mm
|
150 mm
|
10
|
PNP
|
|
Select a variant in the list
