TAKEX
SSPT is a series of curtain photoelectric sensors produced to assist and monitor when a fitter is picking items out of crates. With clear LEDs, the curtain shows a green light where the item is to be picked. If you pick from the wrong crate, a red LED indication comes on. The curtain can of course be used in other applications where a broad detection area is required.
| Approvals | CE |
|---|---|
| Detection height | 100 mm |
| Distance max | 2000 mm |
| Distance min | 0 mm |
| Electrical connection | Embedded 2m cable |
| Function | light on, dark on |
| IP class | IP62 |
| Lens material | Plastic |
| Light type | IR LED |
| Light/dark switching | Yes |
| Material of body | Aluminium |
| Number of bulbs | 5 |
|---|---|
| Output | NPN, PNP |
| Output current max | 0.05 A |
| Photocell technology | Curtain photocell |
| Power consumption max | 0.13 A |
| Reaction time | 25 ms |
| Temperature operational max | 50 °C |
| Temperature operational min | 10 °C |
| Voltage dc max | 24 V |
| Voltage dc min | 12 V |
SSPT is a series of curtain photoelectric sensors produced to assist and monitor when a fitter is picking items out of crates. With clear LEDs, the curtain shows a green light where the item is to be picked. If you pick from the wrong crate, a red LED indication comes on. The curtain can of course be used in other applications where a broad detection area is required.
We are pleased to announce that OEM Automatic Ltd has acquired Motion29 Ltd. Bringing together the expertise, products, and services of both organisations under both the OEM and Motion29 brands, strengthening our overall offering.
Discover how fault masking is compromising the safety of your workplace and find out how OEM Automatic can help you to prevent it completely. Creating a safe and secure work environment.
Learn more about Inxpect radar systems. The worlds first SIL 2/PL d certified, radar-based safety system for use around hazardous machinery.
Whether you're working with opaque materials or transparent items like glass or plastic, these sensors deliver reliable performance across a wide range of applications.
OEM Automatics Safety Experts guide you through the process of setting up your light curtains & barriers, to protect your people and equipment.
Ultra fast-acting fuse links engineered specifically to shield delicate semiconductor devices.
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Parts | Detection height | Number of bulbs | Power consumption max | Reaction time | Price | ||
|---|---|---|---|---|---|---|---|
Light curtain H=100mm 2m
Art:
SSPT205
Copied
|
100 mm
|
5
|
0.13 A
|
25 ms
|
|
||
|
Light curtain H=225mm 2m
Art:
SSPT210
Copied
|
225 mm
|
10
|
0.14 A
|
42 ms
|
|
||
|
Light curtain H=300mm 2m
Art:
SSPT213
Copied
|
300 mm
|
13
|
0.15 A
|
42 ms
|
|
||
|
Light curtain H=375mm 2m
Art:
SSPT216
Copied
|
375 mm
|
16
|
0.155 A
|
58 ms
|
|
Select a variant in the list
