CROUZET MOTORS
Crouzet standard industrial DC motor with inline gearbox for low speed, high torque applications.
DC motors by nature offer a very high starting torque and a suited to a very wide range of applications, the gearbox is 'lubricated for life' to ensure consistent performance.
Options for a bespoke solutions include, different power connections, EMC filter, encoder options & mechanical/electrical adaptations.
| IP class | IP40 |
|---|---|
| Max. torque | 2 |
| Power | 3 W |
| Ratio | i=10→9600:1 |
| Shaft diameter | 6 mm |
| Speed options | 0.3rpm→430rpm |
| Supply voltage | 12 V DC, 24 V DC |
| Type of gearbox | Spur |
| Weight | 0.24 kg |
Crouzet standard industrial DC motor with inline gearbox for low speed, high torque applications.
DC motors by nature offer a very high starting torque and a suited to a very wide range of applications, the gearbox is 'lubricated for life' to ensure consistent performance.
Options for a bespoke solutions include, different power connections, EMC filter, encoder options & mechanical/electrical adaptations.
